Specifications
come with pump, MP12 Filter and UV Sterilizer.
Real factory who manufacture the KOYO brand packing machinery in
China.
Serving the African Market about 20 years.
Capable of producing 2000 sachets per hour.
It can be adjusted to fill sachets or pouches ranging from 70 to
500ml.
Uses a heat-sealing system to ensure that the filled
sachet/pouch/bag does not leak water.
It is designed to use wither PE film or composite film bags with
preprinted logos or without logos.
automatically complete Bag making, filling, sealing, printing,
cutting and counting.
Material:LDPE HDPE/LDPE/LLDPE/PE 100% raw material resin,
environmental protected printing ink.
Appearance:Transparent film,white,black,black and white film rolls
back seal (back-sealing) ensure the products meet state sanitary
standard.
It have power-off protection function(protect machine from power
outage).
1. This water sachet machine has passed the provincial appraisal
and expertise, all the performance indexes reach the Chinese
advanced level of similar products and won the gold prize for
Patent Invention. In 1995, it passed the test of the State Bureau
of Quality and Technical Supervision and was rated as standard.This
series has been long-tested and its performance enjoys a very high
reputation .Up to now, we have owned more than 10000 users in
china, they all reflect that this series is simple in operation and
runs smoothly with low failure rate. The percentage of certified
products is greater than 99%.
2. The plastic bag water filling machine fills the sachet with
water then uses a heat-sealing system to ensure that the filled
sachet or pouch does not leak water. Heat-sealing also ensure that
there are no adhesives, glues, or resins used to seal the bag,
preventing any possible contamination from sealing. The
heat-sealing system uses thermal transverse vertical sealing to
seal the bag, meaning that the bag feeds vertically and is
thermally (heat) sealed.
3. The water sachet packing machine features date lamination, which
laminates the date of production on the bag allowing you to track
which pouches were produced on a given date. It also features
automatic counting to track the number of bags produced by the
machine rather than other machines which do not include this
feature.
4. The liquid filling machine uses UV sterilization when filling
the sachets to prevent any possible contamination. Therefore you
can be sure that the water inside the bag has not been contaminated
after it has been purified by your water purification system.
Main uses:
The liquid packer machine can be used to fill sachet or pouches
with a wide variety of liquid packing such as: water, coconut
water, milk, soya-milk, peanut milk, juice, drinks, dairy, milk,
yogurt, ice bag drinks, soy sauce, vinegar, yellow rice wine and
beancurd, alcoholic beverages, soy milk, and various other liquids.
Use single-layer PE film or two-layer or three-layer co-extrusion
film as packing materials.
Technical Data:
| Model | XY |
| Film developed width(mm) | 160mm-320mm |
| Packing capacity(ml) | 70-500ml |
| Produce Rate | 1500-2000bags/Hour |
| Voltage | 220V/380V |
| Weight | 650KG |
| Size | 1.05*0.95*1.95m |
| Power | 1.5KW |
