RO Water Treatment Plants/KOYO Production Drinking Water Filter
Machine
Adopting the advanced technological process design, all our pure
water treatment with RO system have below advantages to make sure that our customers will get good
tasting, pure, clean water.
Advantages:
High efficiency, low energy consumption, wide application range for
source water, easy to install, convenient to operate. The whole systems adopt American technology RO membrane(
HYDRANAUTICS,DOW etc), which offers various degrees of flux and rejection
characteristics.
Working Process:
It includes Quartz sand filter, active carbon filter, WATER SOFTNERS (WATER CONDITIONER), high
pressure pump, reverse osmosis system, Ozone generator and UV Sterilizer, RO membrane etc.
1. Quartz sand filter -- mainly used for the removal of sediment
from water.
2. Active Carbon filter-- mainly used for chlorine removal and
other organic gases and to clear up the taste of water .
3. Water Softener-- exchange "ions" of calcium and magnesium with
the most common and easiest method.
4. High pressure pump-- Provide the high pressure to RO membrane
ro.
5. RO system-- main part of the plant. The RO membrane's desalting
rate can reach 99%, removing over 99% ions.
6. Ozone generator - Kills 99.9 percent of known harmful bacteria.
Specification:
| Model: | P-RO-1 | P-RO-2 | P-RO-3 | P-RO-5 | P-RO-10 |
| Capacity: | 1000L/H | 2000L/H | 3000L/H | 5000L/H | 10000L/H |
| Pre-Filter: | 2000L/H | 4000L/H | 6000L/H | 10000L/H | 20000L/H |
| Ozone generator: | 5g | 10g | 10g | 20g | 40g |
The price is negotiable. Pls note that all our pure water treatment with RO system can be custom-made to suit your own requirements. We provide the capacity from 0.5T/H to 150T/H, and offer the best
price base on the capacity you need.
Application :
Normally used for potable drinking purposes, but are also used in
hospitals, laboratories, marine industry and industry where the
purest of water is required.
